In industrial plants where coil storage is space-intensive, it is crucial to ensure safe and efficient handling even in very limited space between coils.
For this purpose, we have developed coil tong with folding support armsthat allow precise gripping into the eye of the roll even where there is no space to spare - without damaging the material and without compromising on safety.
Thanks to our compact design and emphasis on safety, we ensure smooth, risk-free operation.
Technical parameters of the device:
| Maximum load capacity: | 25 000 kg |
| Weight of the pliers: | 1 980 kg |
| Scroll length: | 250 - 1 900 mm |
| Outer diameter of the coil: | max. 2 000 mm |
| Inner diameter of the coil: | 500 - 600 mm |
| Drives: | electric - clamping, turning and tilting |
| Control: | remote control, crane operator from the ground |
Key benefits:
✔️ Possibility of operation in confined spaces between coils - aisle approx. 250mm
✔️ Gentle handling - protection of the material when entering the roll mesh
✔️ One person control, fully from a distance
✔️ Non-contact limit switches for trouble-free operation
Do you have similarly demanding storage conditions? We will be happy to design a tailor-made solution for you.
Supplemented - photos from the customer's operation:
